Introduction to TELEC certification:
"Radio Law" requires that the designated radio equipment type approval (that is, technical regulations compliance certification). Certification is mandatory. The certification body is a registered certification body recognized by MIC within the scope of designated radio equipment. TELEC (TelecomEngineeringCenter) is the main registered certification body for Japan radio equipment compliance certification.
TELEC (MIC) certification type:
TELEC (MIC) certification includes test certification (TestCertification) and type certification (TypeCertification). Test certification is to verify each equipment unit. The certification is only valid for each equipment unit that has been verified. Type certification refers to the verification of samples of a batch of equipment of the same design and manufacture. Effective, but if the design or manufacturing of the device changes, the device will need to be recertified. It is worth noting that the use of non-low-power radio stations and their terminal equipment requires a license from MIC. In addition, there are two cases for compliance certification of telecommunications terminal equipment: for ordinary telephone devices, as long as the JATE certification is required in accordance with the Telecommunications Business Law; for wireless terminal equipment, in addition to the JATE certification in accordance with the Telecommunications Business Law, it is also required TELEC certification according to the requirements of the Radio Law.
Information required for wireless charging TELEC certification:
1. The whole machine schematic diagram (Systemblockdiagram)
2. Block diagram of the whole machine (Systemschematic)
3. User Manual (usermanual)
4. Operational description (operational description)
5.BOM
6. Module schematic diagram (moduleschematic)
7. Module block diagram (moduleblockdiagram)
8. Module specification
9. Factory ISO9001 certificate (ISO9001certificateofmanufacturer)
10.label and location map (labellocationlabelsampleDrawingphotos)
11. Antenna specification (antennaspecification): including antenna name, antenna form, antenna gain, antenna measurement chart, antenna appearance and size chart.
Note: The information provided above must be in English/Japanese
TELEC certification process:
TELEC certification for WLAN and Bluetooth products
TELEC is a mandatory certification for wireless products in Japan, which is similar to domestic SRRC. It follows the Japanese radio law. The specific test specification is to follow the MIC (Japan Ministry of Internal Affairs and Communications) Notice No. 88 regulations.
The test items of WiFi and Bluetooth products are basically similar to the European standard EN300328
Among them, the standard used by 2.4GHzWiFi products (802.11b/g, 2412~2472MHz) and Bluetooth products is MICNoticeNo.88Annex43, but for 14 channels of 2.4GHzWiFi products
TELEC certification test items:
1. Frequency error measurement (FrequencyErrorMeasurement)
2. Coupling bandwidth/carrier frequency bandwidth test
(OccupiedBandwidthandSpread-spectrumBandwidth/Factor)
3. UnwantedEmissionIntensityMeasurement
4. Antenna Power Error Measurement (AntennaPowerErrorMeasurement)
5. Receiver spurious harassment test
(LimitationofCollateralEmissionofReceiverMeasurement)
6.EIRP antenna power test
(TransmissionAntennaGain(EIRPAntennaPower) Measurement)
7.3dB lobe bandwidth test
(TransmissionRadiationAngleWidth(3dBBeamwidth)Measurement)
8. Duty Cycle Measurement (DutyCycleMeasurement)
9. Occupation time test (retentiontime)
TELEC certification cycle
The TELEC certification cycle is 3-4 weeks.
